Chain CODEX 06 A-3
- Product code: 0000000020310
- Unit of measurement: Metre
- Tariff group: 7315119000
- Net weight: 0.99 kg
Best price in the last 30 days: 20,22 €
Direct to factory order
DFO – DAP to your place
Best price in the last 30 days: 20,22 €
Direct to factory order
DFO – DAP to your place
| Item group | Chain |
|---|---|
| Subgroup chain | A-type galvanized chains |
| Assembly | Triplex |
| Pitch p | 9.525 mm |
| Roller diameter d1 max. | 5.08 mm |
| Designation | 06 A-3 |
| ISO code | 06 A-3 |
| ANSI code | 35-3 |
| System | Metric |
| Width between inner plates b1 min. | 4.77 mm |
| Pin diameter d2 max. | 3.58 mm |
| Ultimate tensile strength Qmin | 23400 n |
| Average tensile strength Qo | 30500 n |
| Weight per M | 0.99 kg |
